NEXT GENERATION EBIKE TECHNOLOGY
Advanced torque sensing technology offers a seamless and intuitive pedal assist experience. With a helical gear design, the quality is uncompromised while giving you a silent ride. Compact and lightweight, the system offers subtlety and adaptability.
#This product is assembled outside of China and will not be shipped to China, Hong Kong & Macau
*EU LOCKED LEGAL FIRMWARE AVAILABLE UPON REQUEST
*USA/ EU/ CANADA/ UNRESTRICTED (2000W PEAK) POWER MODE AVAILABLE
250W / 750W
FIRMWARE VERSIONS AVAILABLE*
110N.m.
PEAK TORQUE*
3.2KG
WEIGHT WITHOUT CRANKS
34-50T
CHAINRING OPTIONS
68-120MM
BOTTOM BRACKET OPTIONS
PRESSFIT BOTTOM BRACKET
COMPATIBILITY WITH ADAPTER
ADVANCED TORQUE SENSING TECHNOLOGY
Patented torque sensing technology offers one of the best pedal assist sensitivity in the ebike industry. Paired with our in-house firmware tuning and a robust sprag clutch, the CYC torque sensor ensures instant engagement and an intuitive pedal assist experience. CYC is the only company offering splined spindle in this category of motor. Robustly built for real offroad riders.
ULTIMATE COMPATIBILITY
Modular design enables multiple frame fitment with a single motor.
BB OPTIONS
*68-83mm, 100mm, 120mm BSA & Pressfit version available
CHAINRING OPTIONS
34T, 38T & 50T options available.
SPECIFICATIONS
Title | Value |
|---|---|
Compatibility | 68-83mm, 100mm, 120mm BSA & Pressfit version available *Other BB versions may be compatible, please contact us. |
Chainring | 32T with 53T motor chainring, 38T with 63T motor chainring, 40T with 72T motor chainring |
Q Factor | 190mm |
Crank Arm Length | 165mm or 175mm |
Bracket Materials | 7075-T6 |
Total Weight with Crank Set & BB | 5.6 kg |
Weight of Motor & Controller | 3.8 kg |
Colour | Anodized Black |
Overall Efficiency | > 90% |
Max Torque (at Crank) | 200 N.m. (CYC X6) / 280 N.m. (CYC X12) |
Rated Power | 3500W (CYC X6) / 5000W (CYC X12) |
Max RPM (at Crank) | > 300 rpm |
Rated Voltage | 36 - 72V |
DIMENSIONS
SPACER INFORMATION
